FlyingVoice FIP11CP Basic Business IP Phone, Colour Screen, BLF, WiFi, 2x Ethernet, PoE

Please feel free to contact us about this item, and we will recommend an IT Sales and Service Provider in your area.

Resellers: for pricing and to place orders.

In stock email will be sent.
Instock notification already exists.
Order SKU: Supplier Code:

• 2.4” 320x240 pixel color screen
• 3 SIP accounts
• 6 DSS keys
• 6 BLF keys
• 2 x 10/100Mbps Ethernet Ports
• Integrated 2.4GHz WiFi
• HD voice
• PoE
• RJ9 Headset Port
• Stand with 3 adjustable angles
• Wall mountable

The FIP11CP is designed for easy deployment saving companies and service providers time and money on installations. The 2.4 inch colour display comes with a new UI design, providing you with a rich visual experience. The programmable keys offer
extensive productivity-enhancing features.

Other importnat features include PoE, HD voice, and easy access to various Wi-Fi options.

Simple and Easy to Use UI Design
The FIP11CP comes with a simple design yet ergonomic design that is easy to use. Prompts guide you through a simple installation process making it easy to start a voice collaboration.
Flexible Deployment
Whether in your office or conference room, say goodbye to the complex deployments, connect with people the way you like. FIP11CP supports dual 10/100 Mbps ports, PoE and a built-in 2.4G Wi-Fi connection.
HD Voice Quality
FIP11CP provides excellent voice quality. We have created high-definition sound quality solutions for handset and hands-free scenarios, even in a noisy environment.
High Security and Compatibility
All conversations are well protected. We make sure of security algorithms such as configuration files utilising AES, SRTP and TLS call encryption.
The FIP1X series IP phones are widely compatible with SIP-based PBX platforms such as Yeastar, Asterisk, Broadsoft and 3CX.

Audio Features
> HD voice: HD handset, HD speaker
> Wideband Codec: G.722, Opus, AMR-WB(Optional),
> Narrowband Codec: G.711(A/u), iLBC, G.729AB, G.723,
G.726, AMR-NB(Optional)
> DTMF: In-band, RFC 2833 and SIP info
> Full-duplex hands-free speakerphone
Display and Indicator
> 2.4" 320 x 240px Color screen with backlight
> 16 bit depth color
> LED for call and message waiting indication
> Dual-color (red/green) illuminated LEDs for line
 status information
> Intuitive user interface with icons and soft keys
> Multilingual user interface
> Caller ID with name and number
> Power saving
> Configuration: browser/phone/auto-provision
> TFTP/HTTP/HTTPS for Auto Provisioning
> TR069(TR104/TR106)
> Reset to factory, reboot
> Package tracing export, system log
> DNS/DNS SRV (RFC 1706, RFC 2782)
> NAPTR for SIP URI lookup (RFC 2915)
> Cloud device management: FCMS
> DHCP server and DHCP client
Phone Features
> 3 SIP accounts
> Call hold, mute, DND, Redial, auto answer
> One-touch speed dial, hotline, SIP message
> Call forward, call Waiting, call transfer (attended/blind)
> Paging, intercom
> 3-Way conferencing
> Direct IP call without SIP proxy
> Set date time manually or automatically
> Dial rule
> IP conflict detection
> 2.4 GHz Wi-Fi
> Up to 6 DSS/BLF keys
> Phone book (2000 records)
> Black list
> XML/LDAP remote phonebook
> Phonebook search/import/export
> Call history: dialed/received/missed (60 records)
IP-PBX Features
> Anonymous call, anonymous call rejection
> Voice mail, call park, call pickup
> Message waiting indicator (MWI)
Feature Keys
> 3 Line keys
> 7 features keys: message, headset, hold, mute,
 transfer, redial, hands-free speakerphone
> 4 Soft Keys
> 5 Navigate Keys
> Volume+/-
> 2 x RJ45 Ports (Ethernet 10/100 Base-T)
> Support PoE (FIP11CP Only)
> 1 x RJ9 Handset port,
> 1 x RJ9 Headset port
> 1 x Power adapter
Other Physical Features
> Color: Classic Grey
> Stand with 3 adjustable angles
> Wall mountable
> AC/DC Adapter
 AC Input: 100~240V, 50~60Hz
 DC Output: 5V, 1A
> Power consumption (PSU): 1.5-3.5W
> Power consumption (PoE): 1.9-4.5W
> Dimension(W x H x D x T):
 190mm x 188.5mm x 173mm x 41.5mm
> Relative humidity: 10%~90% (No Condensing)
> Storage temperature: -25~ 65°C
> Operation temperature: 0~45°C
Network and Security
> SIP v1 (RFC2543), v2 (RFC3261)
> Call server redundancy supported
> NAT Traversal by STUN
> Proxy mode and peer-to-peer SIP link mode
> IP assignment: Static IP and DHCP
> HTTP/HTTPS web server
> Time and date synchronization using SNTP
> SDP (RFC 2327) , UDP/TCP
> Mutil-VLAN, DSCP and 802.1p QoS
> HTTPS certificate manager
> AES encryption for configuration file
> Digest authentication
> IPv4 /IPv6 ,Dual stack IPv4/IPv6
> RTP/RTCP (RFC 1889, RFC 1890)
> ARP/RARP (RFC 826/903)
> IEEE802.1Q VLAN/802.1p/DSCP
> SNMPv2

Package Contents
- Flyingvoice FIP11CP IP Phone
- Handset with handset cord
- Ethernet cable
- Stand
- Quick start guide

 Power adapter optional
