Ubiquiti ANT-146 24dBi 2.4GHz Dual Polarity airMAX 60cm RocketDish Antenna

Please feel free to contact us about this item, and we will recommend an IT Sales and Service Provider in your area.

Resellers: for pricing and to place orders.

In stock email will be sent.
Instock notification already exists.
Order SKU: Supplier Code:

RocketDish is a Carrier Class Dish Antenna that was designed to seamlessly integrate with Rocket M radios (sold separately).

Rocket M combines the “brains” in one robust unit; pair Rocket M with RocketDish to create powerful 2x2 MIMO PtP bridging applications. This seamless integration gives network architects unparalleled flexibility and convenience.

The Ubiquiti Rocket M radios and AirMax Base Station/Rocket Antennas have been designed to seamlessly work together. Installing Rocket M on AirMax Base Station/Rocket Antennas requires no special tools, you simply snap it into place with the mount provided with the Dual Polarity Antennas.

Frequency Range 2.3-2.7 GHz
Gain 24 dBi
Polarisation Dual-Linear
Cross Polarisation 35 dB min
Max VSWR 1.6:1
Vertical Beamwidth 3.8 deg. (Rx Dish), 6.6 deg. (Tx Dish)
Horizontal Beamwidth 3.8 deg. (Rx Dish), 6.6 deg. (Tx Dish)
Connector Type (2) RP-SMA Female
Dimensions 648 mm diameter
Wind Loading 120 mph
Pole Mount Diameter 38 - 100mm
