QNAP QSW-L3208-2C6T 8-Port Manged Ethernet Switch, 8x or 6x 10GbE Multi-Gig RJ45 Ports (10G/5G/2.5G/1G/100M), 2x Combo 10GbE SFP+ (10G/1G) or Multi-Gig RJ45
- 8-Port 10GbE Flexibility with RJ45 & SFP+
- QSS: Intuitive Network Management Software
- 6 x 10GbE Multi-Gig RJ45 network ports (10G/5G/2.5G/1G/100M)
- 2 x 10GbE SFP+ (10G/1G) / Multi-Gig RJ45 combo ports (fiber/copper)
- Switching capacity of 160Gbps, supports LACP bandwidth aggregation up to 40Gbps
- Lite Managed Features: VLAN, QoS, Port Mirroring, IGMP Snooping
- QSS: Online firmware updates, Qfinder Pro
- Other features: Jumbo Frame 12K, Auto Negotiation, Flow Control, Loop Detection, IEEE 802.3az EEE
Still using unmanaged switches? A small upgrade brings you Lite Managed features like LACP, VLAN, QoS, and traffic monitoring—empowering you to control key connections, boost transfer efficiency, and simplify troubleshooting.
The QSW-3000 series QSW-L3208-2C6T has eight full 10GbE Multi-Gig/fiber ports, ensuring smooth performance for video editing, backup, and video surveillance. Whether you're a content creator, media team, or small office, it’s easy to deploy—no IT skills required.
Designed and manufactured in Taiwan, the QSW-L3208-2C6T delivers reliable and secure networking quality.
10G Multi-Gig Connectivity
6× 10GbE RJ45 ports (10G/5G/2.5G/1G/100M) and 2× combo ports (10GbE SFP+ [10G/1G] / RJ45 [10G/5G/2.5G/1G/100M]) for diverse network connections.
Boost Your Bandwidth
Supports LACP for up to 40Gbps aggregated bandwidth—ideal for editing teams and high-speed NAS environments.
Prioritize Critical Transfers
QoS / CoS / DSCP enable intelligent traffic prioritization. Ensure uninterrupted VoIP, streaming, and backups, while VLAN isolates departments for cleaner traffic segmentation.
Faster Large File Transfers
Supports 12K jumbo frames to accelerate large data transfers and reduce packet loss.
Stream Smoother Video
IGMP Snooping enhances multi-stream performance, perfect for IPTV and NVR. Works seamlessly with NAS.
Online Firmware Updates
QSS (QNAP Switch System) supports online firmware checks and Qfinder Pro, enabling one-click updates.
|
Management Type |
Lite Managed |
|
Number of Ports |
8 |
|
10GbE BASE-T (RJ45) |
6 10G/5G/2.5G/1G/100M |
|
10GbE SFP+/RJ45 Combo Ports |
2 Note: The 10GbE SFP+ ports are backward compatible with 1GbE SFP; the RJ45 (copper) combo port supports up to five speeds (10G/5G/2.5G/1G/100M). |
|
Power Supply Description |
Adapter |
|
Max. Power Consumption |
36W |
|
Input Power Type |
DC |
|
Input Voltage Range |
12V/3A |
|
MAC Address Table |
16K |
|
Total Non-Blocking Throughput |
80Gbps |
|
Switching Capacity |
160Gbps |
|
Management Interface |
Web |
|
Console |
RJ45 |
|
Energy Efficient Ethernet (IEEE 802.3az complaint) |
|
|
Fan |
System: 4 x 4 cm (12V) |
|
Supported Standards |
IEEE 802.3 Ethernet |
|
Form Factor |
Desktop |
|
LED Indicators |
Per Port: Speed/Link/Activity |
|
Buttons |
Reset button |
|
Dimensions (HxWxD) |
44 x 210 x 160 mm |
|
Weight (Net) |
1.29 kg |
|
Weight (Gross) |
2.61 kg |
|
Operating Temperature |
0˚C to 40°C (32°F to 104°F) |
|
Relative Humidity |
0~90% non-condensing |
|
Certifications |
CE, UKCA, FCC, IC, VCCI, RCM, BSMI, LVD, KC |
|
Electromagnetic Compliance |
CLASS A |
|
Jumbo Frames |
12K |
|
Warranty |
2 Years |
