The OmniTik 5 ac features five Gigabit Ethernet ports and 802.11ac WiFi.
It is equipped with a powerful 720MHz CPU, 128MB RAM, high power 1,300mW 802.11a/n/ac Dual Chain wireless (support for AC as well as backwards compatible with 802.11a/n devices).
It also comes with a new design weatherproof outdoor enclosure, two integrated 7.5dBi 5GHz omni antennas, a power supply, a PoE injector, and a mounting kit.
The OmniTik 5 PoE ac supports passive or standard 802.3at/af PoE input/output (12v-57v). Ethernet ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. Less power adapters and cables to worry about!
It can power 48V devices (like IP cameras), if 48V input is used.
Max Power consumption : 18W
PoE in : Passive PoE
PoE out : 802.3af/at
PoE in input Voltage : 12-57 V
Number of DC inputs : 1 (PoE-IN)
Wireless 5 GHz number of chains : 2
Wireless 5 GHz standards : 802.11a/n/ac
Antenna gain dBi for 5 GHz : 7.5
Wireless 5 GHz chip model : QCA9892
10/100/1000 Ethernet ports : 5
Number of USB ports : 1
USB Power Reset : Yes
USB slot type : USB type A
Max USB current : 1A
PCB temperature monitor : Yes
Voltage Monitor : Yes
Pole mounting bracket
Metal ring (one)
Gigabit PoE injector
28V 2.57A power adapter
Use CAPsMan to allow centralisation of wireless network management.
You can use the Mikrotik capsman to manage multiple access points and enable roaming between them. This will ensure that users can roam from one access point to the other without loosing connections. Capsman stands for controlled access point system manager. It allows network administrators to manage multiple Mikrotik access point from a central location.
• Centralised management of RouterOS Access Point
• Dual Band AP Support
• Provisioning of APs
• MAC and IP Layer communication with APs
• Certificate support for AP communication
• Full and Local data forwarding mode
• RADIUS MAC authentication
• Custom configuration support
• Automatic upgrade of all CAP clients
• L2 Path MTU discovery
