Ubiquiti U6-LITE Wi-Fi 6 Access Point, 802.11ax, dual-band 2x2 MIMO

Wi-Fi 6 Access Point in a compact design for low-profile mounting.

Please feel free to contact us about this item, and we will recommend an IT Sales and Service Provider in your area.


Resellers: for pricing and to place orders.

In stock email will be sent.
Instock notification already exists.
Order SKU: Supplier Code:

The Ubiquiti UniFi 6 Lite is a 2x2 Wi-Fi 6 access point that delivers up to 1.5 Gbps aggregate radio rate with 5 GHz (MU-MIMO and OFDMA) and 2.4 GHz (MIMO) radios.

Mount the UniFi 6 Lite horizontally in the ceiling to cover a high-density environment, or mount it vertically on the wall to extend its range. UniFi 6 Lite has a compact and nano-sized design, so it can use nanoHD covers and mounting accessories.

• 2 x 2 high-efficiency Wi-Fi 6
• 5 GHz band 2x2 MU-MIMO and OFDMA with radio rate of 1.2 Gbps
• 2.4 GHz band 2x2 MIMO with radio rate of 300 Mbps
• Gigabit Ethernet, powered with 802.3af PoE (PoE injector not included)
• Compatible with UAP-nanoHD covers and recessed mounting bracket
• Enclosure Characteristics: Polycarbonate 110 and ADC12 Die Casting
• Mounting Characteristics: Polycarbonate, SGCC Steel
• Managed by UniFi Network Controller version: 5.14.3 or higher

Product Specifications
• Processor Specs 880 MHz MIPS 1004 KEc
• Memory Information: 256 MB
• Management Interface: Ethernet In-Band
• Networking Interface: (1) 10/100/1000 Mbps Ethernet RJ45
• Buttons: Factory Reset
• LEDs: White/Blue
• Power Method: 802.3af PoE, Passive PoE (48V)
• Power Supply: 802.3af PoE; 48V, 0.32A PoE Adapter (Not Included)
• Supported Voltage Range: 44 to 57VDC
• Max. Power Consumption: 12W
• Max. TX Power:
• 2.4GHz: 23 dBm
• 5GHz: 23 dBm
• MIMO:
• 2.4GHz: 2 x 2
• 5GHz: 2 x 2
• Throughput Speeds:
• 2.4GHz: 300 Mbps
• 5GHz: 1201 Mbps
• Antenna Gain:
• 2.4GHz: 2.8 dBi
• 5GHz: 3 dBi
• Operating Temperature: -30 to 607deg; C (-22 to 140° F)
• Operating Humidity: 5 - 95% Non-condensing
• Certifications: CE, FCC, IC
Software
• Wi-Fi Standards:
• 802.11a/b/g
• Wi-Fi 4/Wi-Fi 5/Wi-Fi 6
• Wireless Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
• BSSID: 8 per Radio
• VLAN: 802.1Q
• Advanced QoS: Per-User Rate Limiting
• Guest Traffic Isolation: Supported
• Concurrent Clients: 300+

Product Includes
(1) UniFi Lite Access Point
(1) Mounting Plate
(1) Allen Wrench
(1) Set of Screws
