Ubiquiti USP-RPS UniFi Redundant Power System

UniFi Redundant Power System

Please feel free to contact us about this item, and we will recommend an IT Sales and Service Provider in your area.


Resellers: for pricing and to place orders.

In stock email will be sent.
Instock notification already exists.
Order SKU: Supplier Code:

The UniFi SmartPower Redundant Power System, model USP-RPS, is a proprietary redundant power system designed to protect up to six UniFi SmartPower supported devices from sudden power supply module failure.

The USP-RPS continually monitors all attached devices. In the event of an internal AC/DC power supply failure, failover is automatic so your network continues to operate with no interruption in service.

With a 950W DC power budget, the USP-RPS can protect a variety of high-power devices, including UniFi PoE switches. An integrated 1.3" color touchscreen LCM displays system information for convenient monitoring.

  • (6) USP DC output ports
  • (1) Ethernet port
  • 1U Rackmountable (kit included)
  • 1.3" Touchscreen display with status information

With a 950W (12V 350W / 54V 600W) DC power budget, the USP-RPS can protect a variety of high-power devices, including UniFi PoE switches.

The following table lists the supported RPS models and their power budget.

Model 52V / 12V
UDM-Pro 0W / 50W
UDM-SE 220W / 0W
UXG-Pro 0W / 30W
UNVR 0W / 130W
UNVR-Pro 0W / 200W
USW-Pro-24 0W /30W
USW-Pro-48 0W / 50W
USW-Pro-24-PoE 400W / 30W
USW-Pro-48-PoE 600W / 50W
USW-Enterprise-24-PoE 400W / 100W
USW-Enterprise-48-PoE 720W / 150W
USW-EnterpriseXG-24 0W / 100W
USW-Pro-Aggregation 0W / 100W

Failover Mechanism
The USP-RPS automatically triggers a seamless failover in the event of an internal AC/DC power supply failure or AC circuit failure on the connected devices.

Power Architectures

Users can select different power architectures to protect the different levels of power failure.

  • Internal power supply failure
  • AC circuit failure
  • Interruption of utility power

Single Port Power Overload
To prevent short circuiting, the USP-RPS monitors power continuously. If the power limit threshold is exceeded, the USP-RPS will cut off power on the port to protect the device and the port's circuit.

PSU Power Overload
The primary purpose of the USP-RPS is to recover the device experiencing the internal power supply failure. For the resilience of power policy, the total backup power can be greater than the PSU capacity of the USP-RPS. In the event of an interruption of power for all devices, the pulse of power could be over the RPS PSU capacity.
