LevelOne GVT-0500 10 Gigabit to SFP+ Media Converter

Please feel free to contact us about this item, and we will recommend an IT Sales and Service Provider in your area.

Resellers: for pricing and to place orders.

In stock email will be sent.
Instock notification already exists.
Order SKU: Supplier Code:

The LevelOne GVT-0500 is a powerful 10 Gigabit media converter which, in combination with the optional SFP+ modules, converts optical into electrical signals.

On existing network infrastructure, the GVT-0500 can quickly improve transmission capacity and expand bandwidth. At the same time, it is a cost-efficent and highly cost-effective solution for managing and operating the system. It is also optimized for ease of operation and maintenance.

- 9K jumbo frames to increase data transfer rates
- Supports low-time lag transmission
- Supports ITU-T DWDM/CWDM wavelengths
- Hot-swappable
- Quick and easy installation

Standards & Protocols:
IEEE 802.3 10-BASE-T, Ethernet
IEEE 802.3u 100-BASE-TX, Fast Ethernet
IEEE 802.3ab 1000BASE-T, Gigabit Ethernet
IEEE 802.3x Flow Control (full-duplex flow control)
IEEE802.3z 1000Base-SX/LX
Ports: Fiber SFP+ slot; RJ-45 Port Cat6A above Twisted Pair cable Auto MDI/MDI-X (Max to 100m) and AutoNegotiation
Indicators: PWR,TX (FDX, 1000, 10G, Link/Act), FX Link/Act
Wavelength (nm): depends on SFP module
Transmission Method: Store and forward (Default)
Power Input: DC 5V/3A
Power Consumption: 1.2W
Operating Temperature (°C): -10 ~ 55 °C
Operating Humidity (Non-condensing): 5 ~ 90 %
Storage Temperature (°C): -40 ~75 °C
Mount: Desk, chassis mounted
Dimensions (W x D x H mm): 115x 85 x 25mm
Weight (g): 300g

Package Contents
Power Adapter
Quick Installation Guide
