MOBOTIX MX-VD1A-2-IR Outdoor Day/Night Dome Camera, Varifocal Lens, Infra-Red LED (25m), 2MP

Outdoor Day/Night Dome Camera, Varifocal Lens, Infra-Red LED (25m), 2MP

Please feel free to contact us about this item, and we will recommend an IT Sales and Service Provider in your area.


Resellers: for pricing and to place orders.

This item is not normally held in stock. We’ll order it in on request. Please contact us for estimated delivery time
In stock email will be sent.
Instock notification already exists.
Order SKU: Supplier Code:
  • 2688 x 1520 at 30 fps
  • Up to 98' of IR Illumination
  • 3-9mm Motorized Varifocal Lens
  • 103-35° Horizontal Field of View

The VD-4-IR from MOBOTIX uses a 1/3" progressive scan CMOS sensor to capture 2688 x 1520 resolution video at 30 fps. A built-in IR LED provides up to 98' of illumination in low-light conditions. The 3-9mm motorized varifocal lens delivers a 103-35° horizontal field of view. Two-way audio communication is possible thanks to an audio input and output. An onboard microSD/SDHC/SDXC slot supports cards up to 128GB. microSD cards are available separately. Integrated PoE technology simplifies connectivity by transferring power and data over one cable.

This dome camera is ONVIF-compliant for profiles S & G, making it compatible with a wide range of surveillance devices. It is equipped with a built-in heater and is IP66- & IK10-rated for outdoor use in areas at risk of vandalism.

  • PoE, 12 VDC, and 24 VAC power
  • Built-in heater
  • Dual iris support (auto and precise iris)
  • Remote zoom, focus, and iris control
  • 10/100M Ethernet
  • Automatically removable IR cut filter enables day and night functionality
  • H.264 and MJPEG video compression
  • Low-latency streaming
  • CBR, VBR, and LBR
  • 120 dB wide dynamic range
  • 2µm pixel size
  • 3x optical zoom
  • 3D motion compensated noise reduction (MCTF)
  • Image settings include color, brightness, sharpness, contrast, white balance, exposure control, 2D-DNR, 3D-DNR, noise reduction by motion masking, and text overlay
  • 90, 180, and 270° rotation in corridor mode
  • Analytics include motion detection, tampering, and audio detection
  • Privacy masking
  • Event triggers include external input, analytics, network failure detection, periodical event, and manual trigger
  • Event actions include external output activation, video and audio recording to edge storage, file upload, FTP, network share, and email notifications
  • Terminal blocks for audio I/O, 4 alarm inputs, 2 alarm outputs, VDC, and VAC power
  • CVBS connector
  • Support for NAS recording
  • IP66- and IK10-rated enclosure that is suitable for outdoor use in areas at risk of vandalism
  • CE, FCC, and LVD certified
  •
