SOPHOS POEZTCHAU PoE Injector, Gigabit Ethernet, 802.3at, PoE+, 30W

Please feel free to contact us about this item, and we will recommend an IT Sales and Service Provider in your area.

Resellers: for pricing and to place orders.

In stock email will be sent.
Instock notification already exists.
Order SKU: Supplier Code:

GigE PoE Injector, 802.3at (30W), with NZ/AU Power Cord

This is a single port, high-power solution for remote powering of current and emerging high power applications. Generating up to 30W, it enables remote power for a new range of applications including 802.11ac Access Points, pan-tiltzoom (PTZ) cameras and video-phones. It complies with the IEEE 802.3at PoE+ standard and is backward compatible with IEEE802.3af. It can power both existing 10/100Base-T network devices and emerging wireless 1000Base-T devices such as wireless IEEE 802.11ac access points and IP Cameras.

  • Single-port Gigabit PoE Midspan, 802.3at Compliant with 2-event classification
  • Backwards compatible with IEEE802.3af
  • 30W output power from -20ºC to +40ºC, 25W output at +55ºC
  • 1000Base-T compatible
  • Safe & reliable power over existing Ethernet infrastructure, only PoE devices receive power
  • Automatic detection and protection of non-standard devices
  • Plug-and-play installation

Pass Through Data Rates: 10/100/1000 Mbps
Power over Ethernet Output Pin Assignment and Polarity: 4/5 (+), 7/8 (–)
Output Power Voltage: 55Vdc
User Port Power: 36W Typ.
Input Power Requirements
AC Input Voltage: 100 to 240 Vac
AC Input Current: 0.8A @100-240 Vac
AC Frequency: 50 to 60 Hz

Dimensions 55 mm (W) x 32.5mm (H) x 140 mm (L)
Weight .44 lbs (200g)

Connectors : Shielded RJ-45, EIA 568A and 568B
